Messersi TC550D | Mini tracked dumper ideal for challenging terrains with payload capacity up to 5000 kg

Mini Crawler Dumper TC550D

Standard equipment

• Tracked dumper with hydrostatic transmission with axial piston pump and two hydraulic motors with double speed.
• Controls are pilot assisted assembled on the 180° rotating driver’s seat.
• STAGE V turbo diesel common rail engine with DEF.
• Auto Two Speed.
• Closed cabine with air conditioning.
• Loading vessel with 180° swivel tipping operated by one slew motor, controlled by joy-sticks.
• 600 mm wide tracks to reduce the ground pressure and overcome all the most slippery and highest gradient slopes.
• Rear camera.
• Versatile track body to be used in a wide range of application (transport, crane and pile drivers mainly), particularly suited to safely drive on soft or muddy ground.

Max payload: 5000 kg (11000 lb)
Engine power: STAGE V 85.9kW (115 hp)
Width: 22000 mm (87 in)
Supply: Diesel
