Messersi TC95D | Mini tracked ride-on dumper ideal for challenging terrains with payload capacity up to 950 kg

Tracked dumper TC95D
TIME SAVING SAFETY ON THE SITE SUITABLE FOR ANY LOCATION AND SOIL (MUD , SLOPES , SAND ETH..)

Standard equipment

• Iidler with new watertight bearings and with a loading capacity increased of 70% than the previous version.
• The engine has been relocated in order to reduce the rear size so to give an higher stability to the empty machine.
• Larger radiator and heat exchanger.
• track built with a monobloc structure incorporating a core of continuous steel wire and heat treated embedded metals.
• diesel engine 13 Hp, water cooled, with electric start as standard equipment.
• transmission consisting in two axial pistons pumps of variable displacement and two orbital motors of fixed displacement, with planetary drives with multiple disk brakes and negative control system.
• P.T.O. (optional) with flow of 20 l/min and pressure of 140 bar.

Max payload

950 kg

2100 lb

Engine power

9.6 kW

13 hp

Width

800 mm

31.5 in

Supply

Diesel
