CWS-DKL-160Wire rope hoist 24m*5mm 160kg 220V

CWS-160 wire winch with high lifting speed suitable for home use. Great ease of installation and great safety as it has terminal switches for ascent and descent.

• Lightweight and compact design Allows easy installation
• Upper hoisting limit switch When rope touches the limit arm, hoisting is automatically stopped
• Lower hoisting limit switch: Sensor arm automatically stops motor if the wire rope is under-wound
• Dynamic and mechanical ratched brakes: Double ratchet pawl brakes provide instant and safe braking
• Can operate on standard domestic power supply
• Wire rope comes with a safety-latch weight hook
• IP44 Motor engine
• IP65 waterproof remote control with safety switch with 10m cable.
• Power cable 5m.

• Lifting capacity: 160kg at wire rope top layer
• Lifting speed: 9 – 14 m/min
• Motor rating IP44:
  1 phase, 110V : 1.2 kw x 12 A series wound
  1 phase, 220-240V: 1.2 kw x 6 A  series wound
• Gear ratio: 272:1
• Maximum lifting height: 24 m
• Braking methods:
  for motor: Electromagnetic
  for gear: Double mechanical ratchets
