Electric stair climber 150kg,600mm stroke

BUDDY LIFT PLASMOID

• Leaving the load on the level of the flat ground requires more space for turning. It is a matter of physics. Buddy Lift - Plasmoid features an integrated lifting base that makes it possible to recover the necessary space and turn on tighter stairs.
• Buddy Lift Plasmoid lifts the load up to 60 cm / 23 inches off the ground, thereby making loading and unloading possible on most commercial vehicles for home deliveries.
• It is simple and intuitive to use.
• Stair climbing trolley and built-in load lifting. Self-loading.

Safety, handling and speed

• The Buddy Lift Plasmoid powered stair climber is equipped with both tracks and wheels. At the push of a button, the operator can choose to use the tracks or the wheels. The wheels are ideal for moving on level ground, turning on landings, and moving through hallways and doorways.
• The non-slip tracks provide maximum load stability when transporting ladders. An electric piston controls the tipping of the tracks and the electric lifting of the load.

The hand truck stair climber for heavy loads: up to 150kg load capacity

• With Buddy Plasmoid you can transport heavy loads of up to 150kg without any physical effort. Thanks to the electric piston that drives the tracks, there is no interference between the tracks and the wheels.
• With the push of a button, you can activate the tracks on the stairs and switch back to the faster electric drive of the wheels when you go through a door, corridor or other flat surface.

Moving a washing machine upstairs has never been so easy

• Washing machine, refrigerator and all other household appliances can be effortlessly transported up the stairs with the Buddy Lift electric stairclimber.
• The Buddy Lift is self-loading and has an electric load lifting system of up to 24 in.
• In addition, it modulates the center of gravity of the load by moving it along the structure of the electric lift while driving. This ensures absolute driving comfort with maximum load stability.

‍

Technical information

• Maximum Capacity: 150 Kg
• Max Depth: 599
• Overall width: 579
• Support length: 348
• Height of handle above the ground: 1202
• Stair climbing trolley weight without battery: 72 Kg
• Battery pack weight: 11 Kg
• Structure adjustable in height: 1920
• Running speed on stairs: 47 steps per minute
• Type of battery: 24V 20Ah Lead gel without memory effect
• Battery life: about 400 steps
• Landing manoeuvring space: With a 60x60 cm load it can turn on a 80x80 cm landing
• Degree of protection: IP54

• 1 automatic battery charger
• 1 Fixing strap
• 1 Standard battery pack
• 1 Standard base
