BOCKER Rack and Pinion Hoist Super-Lift S 225
- Stock: Delivery up to 30 days
- Model: 1308
0.00€
0.00€
(With Tax)
The compact material lift
- The Super-Lift S225 has been designed as a compact lift for the safe and efficient transport of material.
- It impresses in particular by its fast and easy assembly.
- All basic components are extremely lightweight.
- Therefore the S225 can be assembled and transported without any difficulties.
- The large loading platform is safely fixed by a single bolt within a short period of time.
- Having a weight of only 15 kg the solid aluminium masts are equally light-weight and extremely easy to assemble.
- At the same time the material lift impresses by surpassing performance and flexibility.
- The S225 has a maximum load-bearing capacity of 200 kg and can be assembled up to a maximum lifting height of 50 m.
- The generously sized platform is even large enough for the transport of euro-pallet so that no transhipping is necessary.
- The Super-Lift S255 needs only minimum space. For operation on narrow construction sites the whole platform is rotatable by 90 degrees.
- At the same time, the safety equipment leaves virtually nothing to be desired.
- Important features such as the speed-governed safety brake and the mast override protection are standard features of the Super-Lift S225.
| Model | S 225 |
| Load bearing capacity | 200 kg |
| Drive system | Cable |
| Loading platform interior dimensions (L x W x H) | 1.40 x 0.85 x 1.10 m |
| Loading height | 0.20 m |
| Lifting height max. | 50 m |
| Mast topper | 1 m |
| Length aluminium mast | 2 m |
| Weight aluminium mast | 15 kg |
| Weight of basic unit including carriage | 120 kg |
| Weight drive system | 54 kg |
| Weight loading platform | 75 kg |
| Tie distance | 2 m |
| Lifting speed max. | 25 m/min |
| Motor capacity | 1.3 kW |
| Fuse | 16 Ampere (träge) |
| Voltage | 230 Volt / 50 Hz |
| Control voltage | 24 Volt |
All rights reserved for changes.
